Installation, Operation and Maintenance Manual
MDE 256 Rev. 1
8.2

PRO2000V4_RED Interface

The following data sent to the PRO2000v4_RED interface. They are the user specified parameters.
Table 2.
Byte
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
It should be noted that every time that PROFIBUS communication is established,
the parameterization string will be sent to the device writing the parameters to the set-up values.
The values in parameterization string shall be modified at the Master station.
Byte 0 - 2
Byte 3
Master Controller (PLC) Commissioning
Name
Storage Format
Fail Safe Action
Delay before initiating safe operation
Safe Position
Timer Open direction – status
Timer Open direction – on time
Timer Open direction – off time
Timer Open direction – start position
Timer Open direction – stop position
Timer Close direction – status
Timer Close direction – on time
Timer Close direction – off time
Timer Close direction – start position
Timer Close direction – stop position
Reserved
Dead band
Motion inhibit
Reserved for DPV1
Storage Format
It defines the format of the variables that are transmitted on 2 or 4 bytes.
The setting of this parameter affects the format of the following data:
Output Data: (if Module 2 is selected)
Position Request
Input Data: (if Module 2 is selected)
Actuator Position, Output Torque
General Maintenance Info: Slot 2, Index 0
Actuator Position, Output Torque, Opening Time, Closing Time,
Contactor Cycles, Motor Run Time, Time Without Power, Utilization Rate
Recent Maintenance Info: Slot 2, Index 1
Recent Contactor Cycles, Recent Motor Run Time, Recent Time
Without Power, Recent Utilization Rate
Value: 0: LSB byte is transmitted first (default setting)
1: MSB byte is transmitted first
Section 8: Master Controller (PLC) Commissioning
Type Range
0
1 byte
1
0
1
1 byte 2
3
4
1 byte 0 - 255
1 byte 0 - 100
1 byte 0
1 byte 1
1 byte 2 - 200
1 byte 1 - 200
1 byte 0 - 100
0
1 byte
1
1 byte 2 - 200
1 byte 1 - 200
1 byte 0 - 100
1 byte 0 - 100
1 byte -
1 byte 1 - 255
1 byte 1 - 255
April 2021
Default EU
LSB first
LSB first
MSB first
Off
Close
Off Open
Stayput
Go to position
4 seconds
50 %
Off
Off
On
2 seconds
2 seconds
0 %
100 %
Off
Off
On
2 seconds
2 seconds
100 %
0 %
- -
10 tenth of %
6 seconds
