Installation, Operation and Maintenance Manual
MDE 256 Rev. 1
10.2.5 Maintenance Commands for PROFIBUS
Guideline Compliance
Slot 1, Index 30, length 1 byte: Maintenance information (Only Write)
Byte
Slot 1, Index 31, length 7 byte: Maintenance information (Read and Write)
Byte
0 - 6
Slot 1, Index 32, length 7 byte: Maintenance information (Read and Write)
Byte
0 - 6
Slot 1, Index 33, length 7 byte: Maintenance information (Read and Write)
Byte
0 - 6
Slot 1, Index 34, length 7 byte: Date and Time (Only Write)
Byte
0 - 6
NOTICE
•
•
•
Data Exchange Mode (Cyclic Communication)
Name
0 Maintenance command
Name
Next Maintenance
time and date
Name
Last Maintenance
time and date
Name
Startup time and date
Name
Current time and date
0 - 99 years: The values 0 - 50 correspond to the years 2000 to 2050; The values 51 - 99
correspond to the years 1951 to 1999.
SU: Standard Time = 0, Daylight Saving Time = 1
Day of week: Monday = 1, Tuesday = 2, Sunday = 7
Section 10: Data Exchange Mode (Cyclic Communication)
Dim
1 byte
Dim Range
Byte 0 and 1 (0 MSB, 1 LSB): 0, milliseconds not provided
Byte 2 (7, 6 bits res): 0, minutes not provided
Byte 3 (7 bit SU, 6 and 5 res): 0, hours not provided
7 byte
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
Dim Range
Byte 0 and 1 (0 MSB, 1 LSB): 0, milliseconds not provided
Byte 2 (7, 6 bits res): 0, minutes not provided
Byte 3 (7 bit SU, 6 and 5 res): 0, hours not provided
7 byte
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
Dim Range
Byte 0 and 1 (0 MSB, 1 LSB): 0, milliseconds not provided
Byte 2 (7, 6 bits res): 0, minutes not provided
Byte 3 (7 bit SU, 6 and 5 res): 0, hours not provided
7 byte
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
Dim Range
Byte 0 and 1 (0 MSB, 1 LSB): milliseconds
Byte 2 (7, 6 bits res): minutes
Byte 3 (7 bit SU, 6 and 5 res): hours
7 byte
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
April 2021
Range EU
bit0 = 1 Clear Recent Data Log
bit1 = 1 Set Torque Reference
EU
EU
EU
EU
