BIFFI ICON3000 Installation, Operation And Maintenance Manual page 40

Section 10: Data Exchange Mode (Cyclic Communication)
April 2021
Slot 1, Index 22, length 27 byte: Warning log: the first three records
Byte
0
1
2 - 8
9
10
11 - 17
18
19
20 - 26
Slot 1, Index 23, length 18 byte: Warning log: the last two records
Byte
0
1
2 - 8
9
10
11 - 17
36
Name Dim
Warning #1: Code 1 byte
Reserved 1 byte
Warning #1:
7 byte
Time and date
Warning #2: Code 1 byte
Reserved 1 byte
Warning #2:
7 byte
Time and date
Warning #3: Code 1 byte
Reserved 1 byte
Warning #3:
7 byte
Time and date
Name Dim
Warning #4: Code 1 byte
Reserved 1 byte
Warning #4:
7 byte
Time and date
Warning #5: Code 1 byte
Reserved 1 byte
Warning #5:
7 byte
Time and date
Installation, Operation and Maintenance Manual
Range
0 - 255
Byte 0 and 1 (0 MSB, 1 LSB): 0 - 59,999 milliseconds
Byte 2 (7, 6 bits res): 0 - 59 minutes
Byte 3 (7 bit SU, 6 and 5 res): 0 - 23 hours
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
0 - 255
Byte 0 and 1 (0 MSB, 1 LSB): 0 - 59,999 milliseconds
Byte 2 (7, 6 bits res): 0 - 59 minutes
Byte 3 (7 bit SU, 6 and 5 res): 0 - 23 hours
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
0 - 255
Byte 0 and 1 (0 MSB, 1 LSB): 0 - 59,999 milliseconds
Byte 2 (7, 6 bits res): 0 - 59 minutes
Byte 3 (7 bit SU, 6 and 5 res): 0 - 23 hours
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
Range
0 - 255
Byte 0 and 1 (0 MSB, 1 LSB): 0 - 59,999 milliseconds
Byte 2 (7, 6 bits res): 0 - 59 minutes
Byte 3 (7 bit SU, 6 and 5 res): 0 - 23 hours
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 months
Byte 6 (7 bit res): 0 - 99 years
0 - 255
Byte 0 and 1 (0 MSB, 1 LSB): 0 - 59,999 milliseconds
Byte 2 (7, 6 bits res): 0 - 59 minutes
Byte 3 (7 bit SU, 6 and 5 res): 0 - 23 hours
Byte 4 (7, 6, 5 bits day week, 4, 3, 2, 1, 0 bits day month): 1 - 7, 1 - 31
Byte 5 (7, 6 bits res): 1 - 12 month
Byte 6 (7 bit res): 0 - 99 years
Data Exchange Mode (Cyclic Communication)
