Ref. Des.
ASSEMBLY: Micro/Control Board (A2), 61-4796
C1,4,6-12,15,16,21-22
24-27,29-31,45-48,64,66-68,74
C2,3
C14,71,75,80,86
C17,38,40-44,49-56,58
C18,23,39,57,63,69,70,72
C65
C73
C76
C85
C87
D2,3,5,8,9,15-19
D4,10
D6
D7
D11
D14
J1,2,5
J8
Q2
Q3
Q4
Q5
Q6
R1
R2
R3
R4,10,11,15,17,24,26
R5
R6,34
R7,66
R12,35,52
R13,14
R18
R19,51
R20
R21
R22,29,39
R23
R25
R27
R28
R30-33
R36,67
R45,46
R47,48
R50
R65
R68,69
Part Number Description
62-0267-002 CAP , 0.1uF 50V CERAMIC
62-2844-001 CAP , 1uF 50V PE
62-0268-001 CAP , 10 uF 16V ELEC.
62-0267-001 CAP , 0.01uF 50V CERAMIC
62-0267-003 CAP , 0.33uF 50V CERAMIC
62-1355-002 CAP , 33pF 50V CERAMIC
62-0268-011 CAP , 22uF 6V ELEC.
62-0267-004 CAP , 100pF 50V CERAMIC
62-1355-003 CAP , 0.047uF 50V
62-1854-001 CAP , 10uF 16V TANT
62-0289-001 DIODE, 1N4148
62-0565-001 DIODE, 1N4004
62-1687-002 DIODE, 1N5371B
62-4854-001 DIODE, LM336Z-5.0
62-0964-001 DIODE, LM385-1.2Z
62-0292-002 DIODE, ZENER 1N5245
62-4857-001 HEADER, 50 PIN DIN W/LATCH
62-2860-001 HEADER, 9 PIN RT ANGLE
62-4859-001 TRANSISTOR, TIP120
62-4852-001 TRANSISTOR, MPS6724
62-4853-001 TRANSISTOR, VN0116N3
62-4239-001 TRANSISTOR, 2N3904
62-1696-001 TRANSISTOR, NPN HIREL, LM395
62-0961-314 RESISTOR, 18.2K 1/4W 1% MF
62-0961-340 RESISTOR, 34.0K 1/4W 1% MF
62-0961-185 RESISTOR, 825 1/4W 1% MF
62-0961-222 RESISTOR, 2.00K 1/4W 1% MF
62-0961-464 RESISTOR, 665K 1/4W 1% MF
62-0961-391 RESISTOR, 115K 1/4W 1% MF
62-0364-039 RESISTOR, 100 1/4W 5% CC
62-0364-081 RESISTOR, 5.6K 1/4W 5% CC
62-0961-254 RESISTOR, 4.32K 1/4W 1% MF
62-0364-027 RESISTOR, 33 1/4W 5% CC
62-0364-056 RESISTOR, 510 1/4W 5% CC
62-0364-079 RESISTOR, 4.7K 1/4W 5% CC
62-0961-231 RESISTOR, 2.49K 1/4W 1% MF
62-0364-063 RESISTOR, 1K 1/4W 5% CC
62-0961-289 RESISTOR, 10.0K 1/4W 1% MF
62-0961-288 RESISTOR, 9.76K 1/4W 1% MF
62-0961-204 RESISTOR, 1.30K, 1/4W , 1%, MF
62-0364-060 RESISTOR, 750 1/4W 5% CC
62-0961-277 RES, 7.50K 1/4W , 1%, MF
62-0364-087 RES, 10K 1/4W , 5% CC
62-0961-318 RES, 20.0K, 1/4W , 1%, MF
62-0364-071 RES, 2.2K, 1/4W , 5%, CC
62-0364-049 RES, 270 1/4W , 5%, CC
62-0364-049 RES, 270 1/4W , 5%, CC
62-0364-039 RES, 100 1/4W 5% CC
R
4-23
