ConMed Sabre 2400 Operators & Service Manual page 69

Ref. Des.
ASSEMBLY: Control Panel (A3), 62-4908
A3
ASSEMBLY: Cover (A4), 61-4930 (Not available as a complete assembly.)
A2
A2
A3
A7
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Part Number Description
62-4908-001 CONTROL PANEL
61-4796-001 ASSY, A2 MICROPROCESSOR PWB
61-4796-002 ASSY, A2 MICROPROCESSOR PWB
62-4908-001 CONTROL PANEL
61-4913-001 A7 DISPLAY ASSEMBLY
62-4781-001 CABLE, FLAT RIBBON, A2
62-7032-001 BRACKET, RIGHT
62-7032-002 BRACKET, LEFT
62-4926-001 BUMPER, RUBBER
62-4286-001 INSULATOR CLAMP , TO220
62-0649-002 LOCTITE #222
62-1575-002 SCREW , 6-32 X .25 SOCKET HD CAP
62-4772-001 SEAL GASKET
62-0343-002 #6 KEP NUT
62-0342-004 #6 NUT
62-1752-001 WIRE BRAID
62-1575-004 SCREW 6-32 X .38 SOCKET HD CAP
62-4774-001 TOP COVER
R
4-25
