ASSEMBLY: Base (A5), 61-4775 (Not available as a complete assembly.)
A1
A1
A1
A5BR1
A5CB1
A5CB1
A1P3
A1P1
A5W1
A6
A1P10
A5W2
A5R1, A5R2
A5R3
A5SP1
A5W2
A5TB1
A5T1
A5T1
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
4-26
Part Number Description
61-4770-002 LED AMP/OUT/HEATSINK ASSY.
61-4770-003 LED AMP/OUT/HEATSINK ASSY.
61-4770-004 LED AMP/OUT/HEATSINK ASSY. IEC HI ISO
62-0257-001 BRIDGE RECTIFIER 400V , 25A
62-0645-004 CIRCUIT BREAKER, THERMAL, 5A
62-0645-005 CIRCUIT BREAKER, THERMAL, 10A
62-4193-006 CONNECTOR, RECEPTACLE, 600V , 6 POS.
62-3682-003 CONNECTOR,.156,HOUSING W/LOCK,3PIN
61-4780-001 HARNESS, FOOTSWITCH, Sabre 2400
61-4173-003 OUTPUT PANEL ASSY., Sabre 2400
62-1389-001 PLUG (.100)
62-4274-002 POWER CORD, ASSY, Sabre 2400
62-0362-005 RESISTOR, 200 OHM, 50W , 1%
62-0362-006 RESISTOR, 5K OHM, 50W
62-0333-001 SPEAKER, 2 1/2'', 100 OHM
62-0327-006 STRAIN RELIEF 5R17-2, RT. ANGLE
62-4168-006 TERMINAL STRIP , 6 POSITION
62-3858-001 TRANSFORMER, Sabre 2400 POWER
62-3858-002 TRANSFORMER, POWER UL/CSA
62-4767-001 BASE, Sabre 2400, DOMESTIC
62-0260-001 CABLE TIE, 3.5''
62-1707-002 CLAMP , FLAT CABLE, 3'' X 1''
62-3682-201 CONNECTOR, TERMINAL 18-24 AWG
62-1388-001 CRIMP TERMINAL
62-0337-002 FOOT, PLASTIC, 5/8'' BLACK
62-4786-001 HANDLE, ROUND, Sabre 2400
62-0259-001 MOUNT, CABLE TIE
62-0753-003 NUT, HEX NYLON, #63-32
62-0343-001 NUT, KEPS #4-40
62-0343-004 NUT, KEPS #20-32
62-0343-002 NUT, KEPS #6-32
62-4814-001 SCREW , #10-24 X 1/2'', SELF TAPPING
62-0377-005 SCREW , #6-32 X 3/8, BHS
62-0383-004 SCREW , #6-32 X 5/16 FHS
62-4172-003 SCREW , #6-32 X 3/8, SBHC
62-4287-003 SCREW , #8-32 X 3/8, BH
62-4878-004 SCREW 4-40 SKT, 5/16
62-4878-008 SCREW 4-40 SKT, 5/8
62-0274-001 SEALANT, RTV
62-2820-003 SPACER, PWB, 3/4''
62-4884-001 TAPE, PTFE #60
62-0287-009 TERMINAL, 1/4'' RING, BLUE
62-0288-005 TERMINAL, FEMALE 16-14 AWG, BLUE
62-0076-002 TERMINAL, FEMALE MOLEX 02-09-1111
62-0272-001 THERMAL COMPOUND
62-0649-002 THREAD SEALANT, LOCTITE 222
62-0339-003 TUBING, PVC-105 .263
62-0339-005 TUBING, PVC-105 .438
62-0622-002 WIRE, HIGH VOLTAGE #22, 10KV
62-0436-005 WIRE, 18 AWG, STRANDED, BLUE
62-0436-002 WIRE, 18 AWG, STRANDED, BROWN
62-2967-002 CONNECTOR IEC, SIDE FLANGE
62-0436-006 WIRE, 18 AWG, STRANDED, GRAY
62-0436-004 WIRE, 18 AWG, STRANDED, YELLOW
62-0436-008 WIRE, 18 AWG, STRANDED, BLK
62-4427-006 WIRE, 24 AWG, STRANDED, ORG/WHT
62-0620-005 HEAT SHRINK TUBING 1/8" BLK
62-5362-001 SPACER, 3/4" ROUND
