4.10 REPLACEABLE PARTS

The following is a list of replaceable parts available from CONMED Corp. See Section 4.9 for ordering
information. Many of the more common parts are available from local electronic suppliers. Not all parts are
used on all assembly versions. Refer to schematics for details.
Ref. Des.
ASSEMBLY: Power Board (A1), 61-4705
BR1
C1, 2
C3
C4,6,21,65
C5
C7
C8,9,36,38,40
C10
C11,13,15,17
C12,14,16,18,25
C20
C22,24,30-34,37,39,41,
44,46,49,51,61
C23
C26,C29
C27,C28
C35,42,47,59,66
C43,45,48,50,55,56,60
C52
C53,54
C62
C63,64
C67
C68
D1
D2-5,12
D6,11,13-16
D7
D8
D17
D18
DS1
F1,3,5,7
F2,4,6,8
J1, 4-7
J2
J3
J8
J9
J10
K1-3
K4
L1
L2
Q1-4
Q5
Part Number Description
62-0258-005 RECTIFIER, KBL01 BRIDGE
62-3314-003 CAP , 820uF 200V ELEC
62-1677-007 CAP , 1.0uF 250V MET PE
62-0267-002 CAP , 0.10uF 50V 20% CERAMIC
62-0268-002 CAP , 47uF 63V ELEC.
62-3314-001 CAP , 4700uF 35V ELEC
62-0267-003 CAP , 0.33uF DIP CER
62-3314-008 CAP , 4700uF 16V ELEC
62-2844-001 CAP , 1.0uF 50V MET PE
62-1677-008 CAP , 0.1uF 400V 10% PE
62-1677-009 CAP , MET PE
62-0267-001 CAP , 0.01uF 50V 20% CER
62-1677-001 CAP , 0.022uF 250V 20% MET POLY
62-1676-003 CAP , 1.5 nF 2000V 10% PP
62-1675-001 CAP , 5.6 nF 2500V 5% PP
62-0268-001 CAP , 10uF, 16V 20% ELECT.
62-1677-004 CAP , 0.33 uF 100V 10% MET POLY
62-0267-004 CAP , 100pF DIP CER
62-1677-005 CAP , 0.22 uF 100V 10% MET POLY
62-1675-003 CAP , 2.7 nF 2000V 5% PP
62-1676-002 CAP , 10 nF 1600V 10% PP
62-1678-002 CAP , 180pF 6KV 20%
62-1678-001 CAP , 150pF 6KV 20%
62-4861-001 DIODE, P6KE12A
62-1683-001 DIODE, MUR4100E
62-0290-002 DIODE, 1N914B
62-1687-001 DIODE, 1N5355A 18V
62-4865-001 DIODE, 1N5401
62-0292-004 DIODE, ZENER, 1N5221B
62-0292-001 DIODE, ZENER, 8.2V
62-4056-001 LED, RED
62-4866-004 FUSE, 3/8A, 2AG
62-4643-046 FUSE, 2.5A, 5x20
62-3598-001 HEADER, STR. PIN
62-4857-001 CONNECTOR, 50 PIN
62-4248-006 CONNECTOR, 6 PIN
62-2845-005 HEADER, 6 PIN
62-3598-003 HEADER, STR. PIN, GOLD
62-2845-001 HEADER, 2 PIN
62-3473-003 RELAY, REED
62-0638-003 RELAY, SPDT 12V
62-4178-001 INDUCTOR 20mH
62-1093-001 INDUCTOR 3.5mH
62-4773-003 TRANSISTOR, NPN, PWR, HI V PLASTIC
62-4242-004 TRANSISTOR, N-CH PWR FET 60V
R
4-21
