ConMed Sabre 2400 Operators & Service Manual page 66

R
Ref. Des.
ASSEMBLY: Power Board (A1), 61-4705 (continued)
Q6
Q7-16
R2
R3,4,30,33,36,39,42,
45,48,55,66-68
R5
R6
R7
R8
R9
R10-13
R14
R15
R17-20
R21
R23
R24,27
R25
R26
R28,29,31-32,34,35,
37,38,40,41,43,
44,46,47,53,54
R49,50
R51,52
R56-63
R64
R65
R69
R70
R70
RV1
TP1-15,17,18
T1
T1
T2
T2
T3
T4
T5
U1
U2
U3-10
XF1,3,5,7
XF2,4,6,8
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
4-22
Part Number Description
62-4242-003 TRANSISTOR, IRF510
62-4239-001 TRANSISTOR 2N3904
62-4243-001 RES, CER, 0.1 5W 5%
62-0364-039 RES, 100 1/4W 5% CF
62-0367-039 RES, 100 2W 5%
62-0364-050 RES, 300 1/4W 5%
62-0364-057 RES, 560 1/4W 5%
62-0364-063 RES, 1K 1/4W 5%
62-0364-048 RES, 240, 1/4W , 5%
62-1693-002 RES, 3.3 3W 5%
62-0364-043 RES, 150, 1/4W , 5%
62-0364-016 RES, 11 1/4W 5%
62-1693-001 RES, 0.33 3W 5%
62-0364-066 RES, 1.3K 1/4W 5%
62-0365-061 RES, 820 1/2W 5% CF
62-0364-081 RES, 5.6K 1/4W 5% CF
62-0364-052 RES, 360 1/4W 5% CF
62-0366-078 RES, 4.3K 1W 5%
62-0364-068 RES, 1.6K 1/4W 5%
62-0364-104 RES, 51K 1/4W 5% CF
62-0364-025 RES, 27 1/4W 5%
62-0364-055 RES, 470 1/4W 5% CF
62-3859-001 RES, 10K 5W 5%
62-4609-002 RES, 27K 2W 5% CF
62-0364-003 RES, 3.3 1/4W 5%
BI05-0081 RES, 1 5W 5% (-004 Assembly ONLY)
62-1693-005 RES, 0.47 3W 5% Power Oxide (-005 ONLY)
62-4594-004 VARISTOR, 17 VAC
62-2725-001 TEST POINT
61-4764-003 TRANSFORMER, BIPOLAR
61-4764-001 TRANSFORMER, BIPOLAR
61-4870-002 TRANSFORMER, CONT. DETECT, -001 ASSY
61-4870-001 TRANSFORMER, CONT. DETECT, -002 ASSY
61-4887-001 TRANSFORMER, MONOPOLAR
62-4177-001 TRANSFORMER, OSCILLATOR
61-4176-004 TRANSFORMER, ISOLATION
62-1709-001 IC, DSOO26 DUAL DRIVER
62-0301-001 IC, NE555 TIMER
62-4238-001 IC, OPTOISOLATOR OPTI 1264A
62-0295-003 FUSE CLIP
62-0295-002 FUSE CLIP
62-4704-001 PWB, Sabre 2400 POWER
62-0274-001 SEALANT, RTV
62-4240-001 STANDOFF, NYLON WIRE 1"
62-0260-001 CABLE TIE 0.085 WIDE
62-0260-002 CABLE TIE 0.190 WIDE
62-3429-003 INSULATOR PAD, TRANSISTOR
62-4765-001 HEATSINK, Sabre 2400
62-4286-002 INSULATOR CLAMPS
62-1575-004 SCREW , #6 SOCKET HEAD CAP
62-4766-001 BRACE, PWB
62-4768-001 BRACKET, MOUNTING
62-4878-007 SCREW #4-40x1/2" SOCKET HEAD CAP
62-4901-001 WASHER #4 COMPRESSION
