ConMed Sabre 2400 Operators & Service Manual page 68

R
Ref. Des.
ASSEMBLY: Micro/Control Board (A2), 61-4796 (continued)
RN1,3
RN2
RN4
RN5
RN6,7
RN8
SW1
TP1-15,19-25
U1
U2
U3
U4
U6
U7
U8,29
U9*
U9*
U10
U11
U12
U13,14
U15
U16
U17
U19,20,21
U22
U23,24,25
U26
U27*
U30
U50
VR1
VR2
XU3,6,10
XU9,27
XU19-21
Y1
N/A
N/A
*When ordering replacement EPROMs, please specify the REV level of the existing EPROM and the part
number and REV level of the A2 Assembly. Upgraded EPROMs will be supplied only on request and only
if they are compatible with REV level of your A2 PWB.
4-24
Part Number Description
62-2861-003 RES, 4.7K, 10PIN SIP
62-2861-008 RES, 4.7K, 11 PIN SIP
62-2861-006 RES, 1.0K 6 PIN SIP
62-2861-005 RES, 4.7K 6 PIN SIP
62-2861-007 RES, 100 8 PIN SIP
62-2861-009 RES, 22K 4 PIN SIP
62-4855-001 SWITCH, SPST N.O. MOM
62-2725-001 TEST POINT
62-1370-001 IC,CD4538
62-4847-001 IC, 74HCTOO
62-2569-002 IC, MICROCONTROLLER, 8 BIT, 80C31
62-3466-004 IC, X24C04 512 x 8 EEPROM
62-3457-001 IC, 8255-2
62-1714-001 IC, 74LS138
62-4848-001 IC, 74HCT573
61-4797-001 IC, Sabre 2400 CONTL PROGRAM EPROM
61-4797-002 IC, Sabre 2400 Program EPROM HI ISO
62-4606-001 IC, 8155-2
62-4849-001 IC, MAX500BCPE
62-3394-001 IC, LM324
62-1374-001 IC, ULN2003
62-1362-001 IC, LM358
62-4850-001 IC, ADC0838ACN
62-1716-002 IC, 74HCT74
62-4851-002 IC, HV5308 32 CHAN SRL/PARL
62-4253-001 IC, 74S140
62-1711-001 IC, 74LS163
62-4254-001 IC, 74LS166
61-4792-001 IC, Sabre 2400 WAVEFORM PROGRAM EPROM
62-1715-001 IC, 74LS02
62-4258-002 IC, LTC1232
62-4603-003 VOLTAGE REG, 5V , 5%, LT1086 CT-5.0
62-0417-005 VOLTAGE REG, 12V 5%, 7812
62-1377-009 SOCKET, 40 PIN DIP
62-1377-008 SOCKET, 28 PIN DIP
62-4858-001 SOCKET, 44 PIN SQUARE
62-1718-002 IC, 20 MHZ OSCILLATOR
62-3429-002 INSULATOR PAD, TRANSISTOR
62-4795-001 PWB, MICRO/CONTROLLER
