4.8 VIEW MODE (dIA 3)
Diagnostics 3 mode allows the monitoring of
internal software variables as an analog voltage
presented at Test Point #5. Each variable rep-
resents an 8-bit number (0-255) as an analog
voltage (0 to 4.98V) or 19.531 mV/bit. To enter
diagnostics 3, enter the "SEL " key. The menu will
display dIA 1. Using the Coag up key select dIA
3, then press the "SEL " key again. The variable
selected for output at Test Point #5 is a number
1 thru 8 which appears in the Bipolar window.
The number may be raised or lowered using the
Foot Coag treadle to raise or the Foot Cut treadle
to lower. See Table 4.9 for a chart of the number
code and it's meaning.

4.9 PARTS ORDERING INFORMATION

To obtain replacement parts or additional infor-
mation regarding your unit, write or phone:
MAIL:
CONMED Corporation
310 Broad Street
Utica, New York 13501
PHONE: (315) 797-8375
1-800-448-6506 Toll Free
or contact your CONMED distributor.
# Variable (output at TP-5)
1 Tone Volume
2 Limit
3 Return Monitor Value
4 RF Current
5 Line Value
6 Expanded Line Value
7 Line Compensation Value
8 Relay and Current Limit
Delay Timer
9 RF Current (Peak)
4-20
Description
Amplitude of Tone Volume Set.
The set value at which the current limit detect circuitry
will trip (HLP-5).
The A.R.M. value.
The actual RF amplifier current value.
This value is compared with Limit.
The AC Line Voltage.
The AC Line value used for Line compensation.
The Line compensation modifier controlling V Base.
The Value of the delay timer (useful for
power-on scope triggering).
The peak RF amplifier current value after the switch was
depressed to activate RF. (Note: The peak value will be
retained when the switch is released. When the switch is
depressed, the peak value will be reinitialized to zero to
obtain new peak values.)
Table 4.9 View Mode (dIA 3)
To ensure prompt service, please include the fol-
lowing information with your order or request:
Model Number
Serial Number
Number Reference Designator and
Description of Part
CONMED Part Number (if known)
Quantity Desired
Mailing or Shipping Address
Preferred Shipping Means (if any)
Purchase Order Number (if applicable)
Your Name
If you are returning a unit, obtain a Return
Authorization Number from CONMED Tech
Services. This number should be marked on the
outside of the carton.
