ConMed Sabre 2400 Operators & Service Manual page 71

Ref. Des.
ASSEMBLY: Output Panel (A6), 61-4173
A1P4-7
A1P6
A1P9
A1P4,P7
A1P5,P9
J1,2,4,5
J3,6
J7
J8
J9-1,-2
J10,12
J11
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Part Number Description
62-3682-201 CONNECTOR, 0.156, TERMINAL TIN
62-3682-004 CONNECTOR, 0.156, HSG, 4PIN
62-3682-202 CONNECTOR, .0156 TERMINAL GOLD
62-3682-003 CONNECTOR, 0.156, HSG, 3PIN
62-3682-002 CONNECTOR, 0.156, HSG, 2PIN
62-0304-002 BANANA JACK, BLK
62-0304-001 BANANA JACK, RED
62-0085-001 SPRING CLIP
62-0801-001 CONNECTOR, PHONE JACK
62-4342-001 CONTACT, POST, .093 DIA. X #4-40
62-0304-004 BANANA JACK, BLU
62-3749-001 JACK, BANANA, MINIATURE, BLK
62-0260-001 CABLE TIE
62-4101-001 COVER WHEEL (WITH SELECTOR WHEEL)
62-0418-006 LOCK WASHER INT TOOTH, 1/4"
62-5107-001 LOCK WASHER INT TOOTH, 3/8"
62-0418-008 LOCK WASHER INT TOOTH, 5/16"
62-0343-001 NUT, KEPS #4-40
62-4109-001 OVERLAY, OUTPUT PANEL
62-3729-001 PANEL, OUTPUT (WITH SELECTOR WHEEL)
62-4196-001 RETAINING RING, EXTERNAL, 3/16
62-4197-001 RETAINING RING, EXTERNAL, 3/32
62-4404-001 SCREW , TYPE B SELF TAP , #4, PAN HD
62-0370-001 SCREW , #6x3/8 SELF-TAPPING
62-0314-001 SOLDER LUG, #6
62-4164-001 SPRING, TORSION
62-0649-004 THREAD SEALANT, TYPE 425
62-0339-003 TUBING, PVC-105
62-4198-001 WASHER, SPRING, 1/4
62-0470-002 WIRE, 22 AWG, BLK
62-0470-004 WIRE, 22 AWG, BRN
62-0470-006 WIRE, 22 AWG, ORG
62-0470-005 WIRE, 22 AWG, RED
62-0622-002 WIRE, HIGH VOLTAGE #22
62-3729-002 PANEL OUTPUT (NO SELECTOR WHEEL)
62-5237-001 OVERLAY, PANEL (NO SELECTOR WHEEL)
R
4-27
