Chapter 3
Device Management
a
The DSR, DCD and DTR pins are connected together internally.
b
The CTS and RTS pins are connected together internally.
c
RI is not connected.
Communication Ports
Connect any of the available Ethernet ports on the device to a management switch and access the ROS-F console
and Web interfaces via the device's IP address. For more information about available ports, refer to
Communication Ports.
Section 3.2

Configuring the Device

Once the device is installed and connected to the network, it must be configured. All configuration management
is done via the RUGGEDCOM ROS-F interface. For more information about configuring the device, refer to the
RUGGEDCOM ROS-F User Guide associated with the installed software release.
20
Pin
Name
RJ45 DB9
Male Female
b
8 7 RTS
c
1 9 RI
RUGGEDCOM RSG2100PF
Installation Guide
Description Comment
Read to Send
Ring Indicator
Chapter 4,
Configuring the Device
