2.2 Water ingress – advisory information for FMEA analysis
Elstat products have been designed to minimise any risks associated with water ingress and all controllers are IPX5 certified.
The OEM or installer is responsible to ensure that local/country laws and regulatory requirements are met.
2.3

ems55 user interface

The user interfaces of the ems55advanced the ems55Radvanced are as follows:
LED indicators:
indicator
compressor
evaporator fan on when evaporator fan is running.
Dimensions are shown in the following diagram:
function
on when the compressor is running
colour
green
red
ems55advanced and ems55Radvanced / General Use
9 of 84
