Input/Data Connections - Altronix NetWay2ES Series Installation Manual

NetWay2ES
Fig. 1
NetWay2ES
2-Port PoE+ Switch
Input:
Output: IEEE 802.3af (15.4W),
PoE PoE
Signal
Input
Input
LED
IEEE 802.3bt
from
IEEE 802.3af/at to IP devices
midspan/
endspan
Optional Earth Ground

Input/Data Connections:

Unit is powered via CAT5e by midspan or endspan. NetWay2ES is not intended to be connected to
outside plant leads and should be installed indoors within the protected premises.
1 . Connect structured cable from port marked [PoE Input] on NetWay2ES to a PoE midspan/endspan
(Fig. 3, pg. 5) .
2 . Using 4-pair CAT5e or higher cable connect PoE load devices to be powered to the ports marked
[PoE+ Output] on NetWay2ES (Fig. 3, pg. 5) . After authentication and classification have been established,
[PoE Signal] LEDs will illuminate indicating PoE presence .
Fig. 3
Yellow LED 10/100 Mbps
Green LED 1000 Mbps
Ground Terminal
IEEE 802.3bt from midspan/endspan
PoE LED indicates Input PoE present
- 4 -
Fig. 1a
PoE (Up to 90W)
IEEE 802.3at (30W),
compliant.
PoE+ PoE PoE+ PoE
Signal Signal
Output Output
Output Output
LED LED
IEEE 802.3af, 802.3at compliant ports rated up to 30W max
PoE
Input
Fig. 2
Ground
IEEE 802.3bt
PoE PoE
PoE+
Signal Output Signal
NetWay2ESWPN
NetWay2ES
2-Port PoE+ Switch
Input: PoE (Up to 90W)
Output: IEEE 802.3af (15.4W),
IEEE 802.3at (30W),
compliant.
PoE PoE PoE+ PoE PoE+
Input Signal Output Signal Output
Input Output Output
LED LED
IEEE 802.3af/at
to IP devices
from
midspan/
endspan
PoE
PoE+
Output Signal
PoE LEDs indicate Output PoE present
PoE
Signal
LED
NetWay2ES Series
