4.5 Weld parameters

Tuning of weld parameters
Weld parameters marked with the arrows
tuned, either off-line (when not welding) or on-line (when welding).
When welding, these parameters can be tuned within the range with immediate
response. Parameters in the Weld tab are easiest to tune.
Parameters that can be tuned in Program mode:
Parameters that can be tuned in Job mode:
Parameters that can be tuned in Job mode with correction:
Application manual - Fronius TPS 320i/400i/500i/600i with RI-FB inside/i interface
3HAC065012-001 Revision: C
• Weld Speed
• Wirefeed speed
• ArcLength Correction
• Pulse/Dynamic Correction
• ArcLength Stabilizer
• Weld Speed
• Weld Speed
• Wirefeed speed (+- 20%)
• ArcLength Correction (+-10 steps)
© Copyright 2004-2021 ABB. All rights reserved.
4 Weld editor interface
4.5 Weld parameters
or in the weld editor can be
