4 Weld editor interface
4.2 Weld editor in Program mode
Continued
Parameter
Arc Length Correction
Pulse/Dynamic Corr.
Arc Length Stabilizer
44
Description
This parameter represents the arc length when welding in syn-
ergic mode the range is -10 to +10. The values apply to the
MIG/MAG standard synergic, MIG/MAG pulse synergic,
MIG/MAG PMC and MIG/MAG LSC welding processes.
(-10% = shorter arc, 0% = value from line, +10% longer arc)
The actual value range in Volts is also shown as, Actual <x.x –
y.y> [V]
Arc-force dynamic correction or pulse correction (pulsed arc).
The range is -10 to +10.The values apply to the MIG/MAG
standard synergic, MIG/MAG pulse synergic, MIG/MAG PMC
and MIG/MAG LSC welding processes.
(-10% = pulse-/dynamic correction, 0% = value from line, +10%
= pulse-/dynamic correction)
Synergic lines support different kind of corrections depending
on the selected process. As for the PMC process the Arc Length
Stabilizer can be set if supported by the synergic line. The Arc
Length Stabilizer will be dynamically shown within the editor.
The range is 0 to +5 V.
(0 V = value from the line, +5V Max Arc Length stabilizer)
