TLP Pro 1230WTG Web Page

To access the touchpanel default web page, enter the IP address of the unit into the web
browser of a PC connected to the same subnet. A log-in page opens.
Figure 19.
1.
2.
TLP Pro 1230WTG Login Page
Username and Password . The factory configured passwords for all accounts on
Enter the
this device have been set to the device serial number. Passwords can be changed during
configuration. Passwords are case sensitive.
NOTE: If the device is reset to default settings, the passwords are reset to the default
extron (for either admin or user ).
password, which is
The touchpanel web page opens:
Figure 20. TLP Pro 1230WTG Web Page
There is a single, read-only page, providing general and network information about the unit.
Setup Menu
Use the (see page 10) or Toolbelt to configure the touchpanel network
settings.
TLP Pro 1230WTG • Configuration Software 21
