1.
If IP addresses are assigned by DHCP, press
Off .
manually, press
When DHCP is off, the Host Name is grayed out and cannot be edited. All
•
addresses can be edited.
When DHCP is on, the Host Name can be edited. The addresses are grayed out
•
and cannot be edited because they are set by the DHCP server.
2.
If DHCP is on, press the
box opens:
Host Name Dialog Box
Figure 7.
Use the keypad to enter a new name, which appears in the
3.
If DHCP is disabled, set the unit IP address, subnet mask, gateway address, and DNS
server address.
a.
Press the button for the address to be edited. A screen opens, showing the address
and a numerical keypad.
IP Address
1 9 2 1 6 8 2 5 4
1 2
4 5
7 8
0
Back
Numeric Pad for Setting IP Addresses
Figure 8.
b. Select an octet and enter the 3-digit value (leading zeroes in the octet are ignored).
NOTES:
•
Octets can have any value between
•
If you attempt to enter an invalid number, for example
89 but the 2 cannot be entered.
the
•
When a valid 3-digit value is entered, the next octet is automatically selected.
OK to save the changes and return to the Network
c. Press
Cancel to return to the Network screen
screen or press
without saving the changes.
4. If you have changed any of the values in the
the background color of the button changes to blue. Press
Apply to apply the new values or press Revert to return to
the previous values without saving the changes. The button
returns to gray.
If you have not made any changes, the
buttons are grayed out.
On . If the IP address is to be assigned
Host Name button to edit the host name. The Host Name dialog
Clear
2 5 1
3
6
9
OK
Cancel
0 and 255 .
Network screen,
Apply and Revert
TLP Pro 1230WTG • Setup Menu
Host Name text box.
892 , you are able to enter
0.0.0.10
Unsaved
0.0.0.10
Saved
Figure 9. IP Address,
unsaved (top) and
saved (bottom).
12
