- Page 1 User Guide TouchLink ® TLP Pro 725T TouchLink Pro Touchpanel Control Systems 68-2831-01 Rev. A 07 17...
-
Page 2: Safety Instructions
Safety Instructions Istruzioni di sicurezza • Italiano Safety Instructions • English WARNING: This symbol, , when used on the product, is AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad intended to alert the user of the presence of uninsulated dangerous avvertire l’utente della presenza di tensione non isolata pericolosa voltage within the product’s enclosure that may present a risk of all’interno del contenitore del prodotto che può... - Page 3 All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks®, registered service marks(SM), and trademarks(TM) are the property of RGB Systems, Inc. or Extron Electronics (see the current list of trademarks on the Terms of Use page at www.extron.com):...
- Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 5 Conventions Used in this Guide Notifications In this user guide, the following are used: WARNING: Potential risk of severe injury or death. AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure.
-
Page 7: Table Of Contents
Contents Introduction Configuration Software ............1 ........14 About the TLP Pro 725T .........1 Configuration Software ..........14 Features ..............1 Installing GUI Designer, Global Configurator, Application Diagram ..........2 and Toolbelt .............15 Using the Software ..........16 TLP Pro 725T Web Pages ........16 Installation Overview ........... - Page 8 TLP Pro 725T • Contents viii...
-
Page 9: Introduction
• Application Diagram • About the TLP Pro 725T The TLP Pro 725T is a tabletop touchpanel with a 7‑inch LCD touch display and a screen resolution of 1024x600. A range of mounting options are available (see Mounting on page 18). -
Page 10: Application Diagram
Supports USB 2.0. • Supports the Extron Control App and Extron Control for Web. • Mounting options for TLP Pro 725T: • Sit on a tabletop — fixed 65° viewing angle. • Threaded holes in baseplate allow for secure mounting to a table. -
Page 11: Installation Overview
The Global Configurator Help File also includes an introduction to that software and sections on how to start a project and configuration. Global Scripter provides an Extron‑exclusive Python library (ControlScript) and Global Scripter modules to get you started. TLP Pro 725T • Installation Overview... -
Page 12: Panel Features
15° from the center axis. When no motion has been detected for a user‑defined period of time, the touchpanel • enters sleep mode. When motion is detected by the sensor, the screen display is restored and active. • TLP Pro 725T • Panel Features... -
Page 13: Rear Panel Features
Cable guide — The LAN/PoE cable is inserted through this hole at the back of the base (see LAN/PoE Connector on the following page). TLP Pro 725T • Panel Features... -
Page 14: Base
Reset Modes). LAN/PoE connector— Attach the LAN/PoE cable to this RJ‑45 port. The TLP Pro 725T ships without a power injector, which must be purchased separately. An Extron IPL Pro control processor must also be connected to the same network domain as the TouchLink Pro touchpanel (see the www.extron.com... - Page 15 La source d’alimentation ne devra pas être fixée de façon permanente à une structure • de bâtiment ou à une structure similaire. Speaker (see figure 4 on the previous page) — Provides audio for video preview and audible feedback from button presses. TLP Pro 725T • Panel Features...
-
Page 16: On-Screen Menus
On-screen Menus On‑screen menus allow initial configuration of the TLP Pro 725T. Setup Menu To open the setup menu, use a screw driver with a fine blade to press the button. The Menu figure 4 Menu button is located on the base of the touchpanel (see on page 6). -
Page 17: Network
The right and left arrows move the cursor inside the text box. Host Name • Click the key to toggle between upper and lower case letters. Shift • Press Enter to save the new name. • TLP Pro 725T • On-screen Menus... - Page 18 Apply Revert the previous values without saving the changes. The button returns to gray. If you have not made any changes, the buttons are grayed out. Apply Revert TLP Pro 725T • On-screen Menus...
-
Page 19: Display
LCD Brightness — Allows you to adjust the screen brightness, using the slider control. • Wake on Motion — Activates the panel from Sleep mode when motion is detected near • the unit. Toggle between TLP Pro 725T • On-screen Menus... -
Page 20: Audio
Menu PIN Communication LED Change Enable Disable Figure 12. Advanced Screen System and GUI Project Panels These panels are read only, providing information about the system, the Global Configurator Project, and the GUI Designer Project. TLP Pro 725T • On-screen Menus... - Page 21 Enter the PIN a second time. When the PIN entered on the second occasion matches the PIN entered on the first occasion, the PIN is set and the dialog closes. Communication LED The LED can be enabled or disabled. TLP Pro 725T • On-screen Menus...
-
Page 22: Configuration Software
After assigning the control functions, the project is rebuilt and uploaded to the control processor and touchpanel. The GUI Designer and the Global Configurator Plus and Professional programs provide versatility and adaptability for configuration and control of an AV system as it grows and evolves. TLP Pro 725T • Configuration Software... -
Page 23: Installing Gui Designer, Global Configurator, And Toolbelt
You need an Extron Insider account to run Global Configurator Plus and Professional. To obtain one, contact the Extron Sales Department. Toolbelt — Click the button next to the program and follow the on‑screen Download • instructions. TLP Pro 725T • Configuration Software... -
Page 24: Using The Software
Subnet Mask: 255.255.255.0 Up Time: 0 day(s) 1 hour(s) 23 minute(s) Mac Address: 00-05-A6-AB-CD-EF License Information System Devices Device Name Part Number Hostname/IP Firmware Upgrades Firmware: Browse Upload Figure 16. TLP Pro 725T Web Page TLP Pro 725T • Configuration Software... -
Page 25: Updating The Firmware
Updating the Firmware Firmware for the TLP Pro 725T can be upgraded using Toolbelt or the touchpanel web page. Before starting, consult your IT team and ensure that the touchpanel has a unique IP address. Downloading Firmware Power on a computer that is connected to the same network as the touchpanel. -
Page 26: Mounting
Desktop Mounting Placement without a mounting kit The TLP Pro 725T can be placed on any suitable flat surface. The unit can be secured to the desktop using two screws. Figure 19. TLP Pro 725T Base Under the table top, mark the location of two mounting holes, 2.88 inches (73 mm) apart. -
Page 27: Reference Material
Network Port Requirements and Licensed Third-Party Software Used by the Touchpanels For information about network port requirements and licensed third‑party software for the TLP Pro 725T touchpanel, please refer to the Pro Series Control Product Network Ports and Licenses Guide, which is available at www.extron.com. Reset Modes... -
Page 28: Reset All Ip Settings
Reset to Factory Defaults mode performs a complete reset to factory defaults (except the firmware): Does everything Reset All IP Settings mode does. • Removes touchpanel user interface layout and configurations. • Resets all touchpanel settings to factory default. • TLP Pro 725T • Reference Material... - Page 29 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
