AHF 005/010 Operating Instructions

2.1.5 Ordering numbers, 500 - 525 V, 50 Hz

I Typical Motor
AHF,N
[AMP] [kW]
10 A 4, 5.5
19 A 7.5, 11
26 A 15, 18.5
35 A 22
43 A 30
72 A 37, 45
101 A 55, 75
144 A 90, 110
180 A 132
217 A 160
289 A 200
324 A 250
370 A 315
506 A 355
578 A 400
Table 2.5: AHF005 and AHF 010, 500-525V, 50 Hz
⋆ Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 500V and assuming typical motor
load. FC 300 is based on an 160% torque application, while FC 100 and FC 200 series are based on 110% torque application.
The pre-calculated filter current may be varying from the input current ratings of FC 100, FC 200 and FC 300 series as stated in the respective
operating instructions, as these numbers are based on different operating conditions.
Ordering Number
AHF 005 AHF 010
175G6644 174G6656
175G6645 174G6657
175G6646 174G6658
175G6647 174G6659
175G6648 174G6660
175G6649 174G6661
175G6650 174G6662
175G6651 174G6663
175G6652 174G6664
175G6653 174G6665
175G6654 174G6666
175G6655 174G6667
2 x 175G6653 2 x 175G6665
175G6652 + 175G6654 175G6664 + 175G6666
2 x 175G6654 2 x 175G6666
®
MG.80.C1.02 - VLT is a registered Danfoss trademark
Danfoss Frequency converter series *
AQUA, HVAC,
Automation NO
Automation HO
PK75-P5K5
P7K5-P11K
P15K-P18K P11K-P15K
P22K P18K
P30K P22K
P37K-P45K P30K-P37K
P55K-P75K P45K-P55K
P90K-P110 P75K-P90K
P132 P110
P160 P132
P200 P160
P250 P200
P315-P400 P250-P315
P355
P500-P560 P400-P500
2 Description
2
9
