Ordering numbers, 440 - 480 V, 60 Hz

I Typical Motor
AHF,N
Used [HP]
19 A 10, 15
26 A 20
35 A 25, 30
43 A 40
72 A 50, 60
101 A 75
144 A 100, 125
180 A 150
217 A 200
289 A 250
324 A 300
370 A 350
Higher ratings can be achieved by paralleling the filter units
506 A 450
578 A 500
648 A 600
• Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on
480V and assuming typical motor load. VLT 5000 series is based on a 160 % torque application, while VLT 6000
and 8000 series are based on 110% torque application.
The pre-calculated filter current may be varying from the input current ratings of VLT 5000, VLT 6000 and VLT
8000 series as stated in the respective operating instructions, as these numbers are based on different operating
conditions.

Ordering numbers, 500 - 525 V, 50 Hz

I Typical Motor
AHF,N
Used [kW]
10 A 4, 5.5
19 A 7.5, 11
26 A 15, 18.5
35 A 22
43 A 30
72 A 37, 45
101 A 55, 75
144 A 90, 110
180 A 132
217 A 160
289 A 200
324 A 250
Higher ratings can be achieved by paralleling the filter units
434 A 315
469 A 355
578 A 400
• Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on
500V and assuming typical motor load. VLT 5000 series is based on a 160 % torque application, while VLT 6000
and 8000 series are based on 110% torque application.
The pre-calculated filter current may be varying from the input current ratings of VLT 5000, VLT 6000 and VLT
8000 series as stated in the respective operating instructions, as these numbers are based on different operating
conditions.
®
MG.80.B5.02 - VLT is a registered Danfoss trademark
Danfoss ordering number
AHF 005 AHF 010
175G6612 175G6634
175G6613 175G6635
175G6614 175G6636
175G6615 175G6637
175G6616 175G6638
175G6617 175G6639
175G6618 175G6640
175G6619 175G6641
175G6620 175G6642
175G6621 175G6643
175G6689 175G6692
175G6690 175G6693
217 A and 289 A units
Two 289 A units
Two 324 A units
Danfoss ordering number
AHF 005 AHF 010
175G6644 175G6656
175G6645 175G6657
175G6646 175G6658
175G6647 175G6659
175G6648 175G6660
175G6649 175G6661
175G6650 175G6662
175G6651 175G6663
175G6652 175G6664
175G6653 175G6665
175G6654 175G6666
175G6655 175G6667
Two 217 A units
180 A and 289 A units
Two 289 A units
AHF 005/010
Typical Danfoss frequency converter series •
VLT 5000 VLT 6000 HVAC VLT 8000 AQUA
5011, 5016 6011, 6016
5022 6022
5027, 5032 6027, 6032
5042 6042
5052, 5062 6052, 6062
5072 6072
5102, 5122 6102, 6122
5152 6152
5202 6172
5252 6222
5302 6272
5352 6352
5452 6402
5502 6502
- 6552
Typical Danfoss frequency converter series •
VLT 5000 VLT 6000 HVAC VLT 8000 AQUA
5006, 5008 6006, 6008
5011, 5016 6011, 6016
5022, 5027 6022, 6027
5032 6032
5042 6042
5052, 5062 6052, 6062
5062, 5072 6062, 6072
5102, 5122 6102, 6122
5152 6152
5202 6172
5252 6222
5302 6302
5352 6352
5452 6402
5502 6502
8011, 8016
8022
8027, 8032
8042
8052, 8062
8072
8102, 8122
8152
8202
8252
8302
8352
8452
8502
8602
8006, 8008
8011, 8016
8022, 8027
8032
8042
8052, 8062
8062, 8072
8102, 8122
8152
8202
8252
8302
8352
8452
8502
