2 Description

2.1.2 Ordering numbers, 380 - 415 V, 50 Hz

I Typical Motor
AHF,N
[AMP]
2
10 A
19 A
26 A
35 A
43 A
72 A
101 A
144 A
180 A
217 A
289 A
324 A
370 A
506 A
578 A
648 A
Table 2.2: AHF 005 and AHF 010, 380V - 415V, 50Hz
⋆ Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 400V and assuming typical motor
load (4 or 2 pole motor). (FC 300 is based on an 160% torque application, while FC 100 and FC 200 Series are based on 110% torque application.)
The pre-calculated filter current may be different than the input current ratings of FC 100, FC 200 and FC 300 series as stated in the respective
operating instructions, as these numbers are based on different operating conditions.
6
Ordering Number
[kW] AHF 005
4 175G6600
7,5 175G6601
11 175G6602
18,5 175G6603
22 175G6604
37 175G6605
55 175G6606
75 175G6607
90 175G6608
110 175G6609
132 175G6610
160 175G6611
200 175G6688
250 175G6609 + 175G6610 175G6631 + 175G6632
315 2 x 175G6610
355 2 x 175G6611
MG.80.C1.02 - VLT
Danfoss Frequency converter series *
AQUA, HVAC,
AHF 010
Automation HO
175G6622 PK37 - P4K
175G6623 P5K5 - P7K5
175G6624 P11K
175G6625 P15K-P18K
175G6626 P22K
175G6627 P30K-P37K
175G6628 P45K-P55K
175G6629 P75K
175G6630 P90K
175G6631 P110
175G6632 P132
175G6633 P160
175G6691 P200
P250
2 x 175G6632 P315
2 x 175G6633 P355
®
