AHF 005/010 Operating Instructions

2.1.3 Ordering numbers, 380 - 415 V, 60 Hz

I Typical Motor
AHF,N
[AMP] [HP]
10 A 6
19 A 10, 15
26 A 20
35 A 25, 30
43 A 40
72 A 50, 60
101 A 75
144 A 100
180 A 125
217 A 150
289 A 200
324 A 250
370 A 300
506 350
578 A 450
648 A 500
Table 2.3: AHF 005 and AHF 010, 380V - 415V, 50Hz
⋆ Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 400V and assuming typical motor
load (4 or 2 pole motor). (FC 300 is based on an 160% torque application, while FC 100 and FC 200 Series are based on 110% torque application.)
The pre-calculated filter current may be different than the input current ratings of FC 100, FC 200 and FC 300 series as stated in the respective
operating instructions, as these numbers are based on different operating conditions.
Ordering Number
AHF 005 AHF 010
130B2540 130B2541
130B2460 130B2472
130B2461 130B2473
130B2462 130B2474
130B2463 130B2475
130B2464 130B2476
130B2465 130B2477
130B2466 130B2478
130B2467 130B2479
130B2468 130B2480
130B2469 130B2481
130B2470 130B2482
130B2471 130B2483
130B2468 + 130B2469 130B2480 + 130B2481
2 x 130B2469 2 x 130B2481
2 x 130B2470 2 x 130B2482
®
MG.80.C1.02 - VLT is a registered Danfoss trademark
Danfoss Frequency converter series *
AQUA, HVAC,
Automation NO
Automation HO
PK37-P4K
P5K5 - P7K5
P11K
P15K-P18K P11K-P15K
P22K P18K
P30K-P37K P22K-P30K
P45K-P55K P37K-P45K
P75K P55K
P90K P75K
P110 P90K
P132 P110
P160 P132
P200 P160
P250 P200
P315 P250
P355 P315
