2 Description

2.1.4 Ordering numbers, 440 - 480 V, 60 Hz

I Typical Motor
AHF,N
[AMP]
2
10 A
19 A
26 A
35 A
43 A
72 A
101 A
144 A
180 A
217 A
289 A
324 A
370 A
434 A
578 A
659 A
Table 2.4: AHF005 and AHF010, 440 - 480 V, 60 Hz
⋆ Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 480V and assuming typical motor
load. FC 300 is based on an 160% torque application, while FC 100 and FC 200 series are based on 110% torque application.
The pre-calculated filter current may be varying from the input current ratings of FC 100, FC 200 and FC 300 series as stated in the respective
operating instructions, as these numbers are based on different operating conditions.
8
Ordering Number
[HP] AHF 005
6 130B2538
10, 15 175G6612
20 175G6613
25, 30 175G6614
40 175G6615
50, 60 175G6616
75 175G6617
100, 125 175G6618
150 175G6619
200 175G6620
250 175G6621
300 175G6689
175G6690
350 2 x 175G6620
450-500 2 x 175G6621
550-600 175G6690 + 175G6621 175G6693 + 175G6643
MG.80.C1.02 - VLT
Danfoss Frequency converter series *
AQUA, HVAC,
AHF 010
Automation HO
130B2539 PK37-P7K5
175G6634 P11K
175G6635 P15K
175G6636 P18K-P22K
175G6637 P30K
175G6638 P37K-P45K
175G6639 P55K
175G6640 P75K-P90K
175G6641 P110K
175G6642 P132
175G6643 P160
175G6692 P200
175G6693
2 x 175G6642 P250
2 x 175G6643 P315-P355
P400
®
