Ordering numbers, 380 - 415 V, 50 Hz

AHF 005 and AHF 010, 380V - 415V, 50Hz
I Typical Motor
AHF,N
Used [kW]
10 A 4, 5.5
19 A 7.5
26 A 11
35 A 15, 18.5
43 A 22
72 A 30, 37
101 A 45, 55
144 A 75
180 A 90
217 A 110
289 A 132, 160
324 A
370 A 200
Higher ratings can be achieved by paralleling the filter units
434 A 250
578 A 315
613 A 355
648 A 400
Please note that the matching of the typical Danfoss adjustable frequency drive and filter is pre-calculated
based on 400V and assuming typical motor load (4- or 2-pole motor). VLT 5000 series is based on a max.
160 % torque application, while VLT 6000 and 8000 series are based on a max. 110% torque application.
The pre-calculated filter current may be different than the input current ratings of the VLT 5000, VLT 6000,
and VLT 8000 series as stated in the respective instruction manuals, as these numbers are based on
different operating conditions.
4
Danfoss ordering number
AHF 005 AHF 010
175G6600 175G6622
175G6601 175G6623
175G6602 175G6624
175G6603 175G6625
175G6604 175G6626
175G6605 175G6627
175G6606 175G6628
175G6607 175G6629
175G6608 175G6630
175G6609 175G6631
175G6610 175G6632
175G6611 175G6633
175G6688 175G6691
Two 217A units
Two 289 A units
289 A and 324 A units
Two 324 A units
AHF 005/010
Typical Danfoss adjustable frequency drive series
VLT 5000 VLT 6000 HVAC
5006, 5008 6006, 6008
5011 6011
5016 6016
5022, 5027 6022, 6027
5032 6032
5042, 5052 6042, 6052
5062, 5072 6062, 6072
5102 6102
5122 6122
5152 6152
5202, 5252 6172, 6222
5302 6272
5352 6352
5452 6402
5502 6502
6552
MG.80.B4.22 - VLT is a registered Danfoss trademark
VLT 8000 AQUA
8006, 8008
8011
8016
8022, 8027
8032
8042, 8052
8062, 8072
8102
8122
8152
8202, 8252
8302
8352
8452
8502
8602
