Product Description - probst SH-3500-B Operating Instructions Manual

2 | Product Description

2 Product Description
OF
4 / 24
MTB NP
EB GB
IN Suction connection
OUT Discharge connection
OFP Oil fill plug
OSG Oil sight glass
ODP Oil drain plug
EB Eye bolt
GB Gas ballast valve
NOTE
Technical term.
In this instruction manual, we consider that the term 'machine' refers to the 'vacuum
pump'.
OS EF IN
OFP OSG
MTB
EF
NP
OF
AF
OS
0870157201_RA0025-0040F_A0002_IM_en
OUT AF
ODP
Motor terminal box
Exhaust filter
Nameplate
Oil filter
Axial fan
Oil separator
