Intended use

This lifting device (SH-3500-B) is for lifting and transporting at low heights (<1.8 m) flat, air-impermeable
and non-porous stone slabs of granite, marble, WET CAST and other materials as well as concrete elements,
natural stones, sandstone, stairs, clay pipes, etc., provided a vacuum of –0.6 bar is available, using
appropriate transportation or lifting apparatus (crane, chain hoist, construction vehicle, etc.).
●
Die Last wird zusätzlich mit der serienmäßigen Lastsicherungskette gesichert.
●
Various suction plates can be fitted to the device (SH-3500-B) via a quick release locating pin, enabling it
to be used for many different purposes and with many different loads.
●
The permissible load of the device (SH 2500uni b) of 2500kg must not be exceeded!
●
Für die unterschiedlichen Einsatzwecke und Lasten gibt es diverse Saugplatten, die durch einen
Schnellwechselverschluss an das Gerät (SH-3500-B) angebaut werden.
●
Die zulässige Traglast (WLL) des Gerätes (SH-3500-B) von 2.500 kg darf nicht überschritten werden.
Dieses Gerät ist mit
folgenderSicherheitseinrichtung
ausgestattet:
WARNING
9
•
Safety vacuum storage tank.
•
Vacuum gauge.
•
Pressure relieve valve.
•
Warning device (audible).
•
Integrated load-securing chain with chain box and
•
Optional spreader bar TRA (with load-securing chain) for
the multiple attachment of suction plates to the vacuum
lifting device
ATTENTION: The use of this device is only permitted in proximity to the
ground (→ chapter "Safety at work").
Risk of falling objects from using unsuitable suction plates.
►
The suction plate is not included in delivery. The user must ensure that only suction
plates suitable for the load to be lifted are used.
Maximum carrying capacity/working load limit (WLL) 3,500 kg (see also chapter 3).
►
The suction plate holder must comply with the requirements outlined in chapter
5.3. Other suction plate holders are not permitted.
►
The suction surface of the load to be lifted must be airtight – that is, when the
power supply is switched off, the load being gripped must be held for another five
minutes. You may need to verify this by performing tests.
►
The loads to be lifted must be rigid to ensure they are not destroyed during lifting.
Only suction plates of the manufacturer PROBST shall be used, which shows doubtless a
maximum load capacity at a pressure of - 0.6 bar (- 7.8 psi) at the carrying capacity
sticker. In unclear circumstances the vacuum device and the suction plate may not be
put into operation. The manufacturer must be contacted!
