TECHNICAL DATA

3 Technical data
Max. lift capacity*
Weight (incl. liquids, without suction plate)
Vacuum reservoir volume
Nominal suction rate of the vacuum pump
Power of gasoline motor
Fuel type
Volume of fuel tank
Vacuum**
Operating temperature range
Voltage of starter battery
Medium to be pumped
*) The maximum of the suction plate determines the maximum carrying
capacity/working load limit (WLL) of the overall system and may not exceed 3,500 kg.
Suction plates are not included in delivery, see also chapter 5.3.
**) Vacuum required to reach the carrying capacity/working load limit (WLL) of the
suction plate
DANGER
22
•
USA
•
Outside of USA
Risk of injury from exceeding load capacity
►
The permissible load capacity of the means of transportation or lifting (e.g. crane,
chain hoist, construction vehicle, etc.) and the hoist must be at least as high as the
combined weight and load capacity of the lifting device.
3,500 kg (7,700 lbs)
approx. 180 kg (395 lbs)
approx. 32 l
approx. 48 m³/h
4.0 kW at 3,600 rpm
Lead-free gasoline
Pump Octane Number 86 or higher
Research Octane Number 91 or higher
Pump Octane Number 86 or higher
3.6 l
600 mbar vacuum
3°C to 40°C
DC 12 V
Ambient air
