Led "Link / Act. P1; Led "Link / Act. P2; Led "(Profinet) State; Led "Power - Softing echolink one2PROFINET Instruction Manual

Softing Industrial Automation GmbH
This LED is connected directly to the supply voltage of the PROFINET-side.
9.3.2

LED "Link / Act. P1"

This LED is directly controlled by the PROFINET-processor and shines when the gateway at Port
1 (X3 P1) is in an operable network (link-pulses are received) and it flickers when network data
traffic takes place.
9.3.3

LED "Link / Act. P2"

This LED is directly controlled by the PROFINET-processor and shines when the gateway at Port
2 (X3 P2) is in an operable network (link-pulses are received) and it flickers when network data
traffic takes place.
9.3.4

LED "(PROFINET) State"

Off
Lights green
Flashes green
Flashes red
9.3.5

LED "Power"

This LED is connected directly to the supply voltage of the serial interface (RS232/422/485).
9.3.6

LED "State"

Lights green
Flashes green
Flashes green/red
Lights red
Flashes red
9.3.7

LEDs 1 / 2 / 4 / 8 (Error No. / Select ID)

If these 4 LEDs flash and LED "State" simultaneously lights red, the error number is displayed in
binary notation (conversion table, see Annex) in accordance with the table in chapter "Error
handling".
15.1.15
Waiting for Script command "Bus Start"
Connection with IO-controller available, data exchange active
PROFINET initialized. Waiting for connection with IO-controller
PROFINET flash indication
Data exchange activ via serial interface
RS-interface OK, but no constant data exchange
No data exchange since switching on
General Gateway error (see LEDs Error No.)
echolink one is in the configuration / test mode
echolink one2PROFINET V. 1.0
Hardware ports, switches and LEDs
44
