Technical data
UL/CSA certification information
Considered standards
UL mark
UL control number
Tab. 81: UL/CSA certification information
Electrical Data and Ambient Conditions UL
Overvoltage category
Pollution degree
Protection class
Installation site
Max. installation height
SCCR (short circuit current rating) 5000 A
Tab. 82: Electrical Data and Ambient Conditions UL/CSA
– Use 60/75 °C copper conductors only:
– [X6], motor connection
– [X9], load and logic voltage
– Use in an environment with pollution degree 2 (or better).
– Maximum surrounding air temperature: 50 °C
– With correct parameterisation of the nominal motor current, the motor is protected against over-
loading by the I²t monitoring function.
– For the load voltage supply, the use of a suitable fuse is recommended in accordance with the
following table.
Fuse requirements
Overcurrent protective device
Max. permissible rated
current
Min. short circuit cur-
rent rating SCCR of
mains fuse
Min. rated voltage
Tab. 83: Fuse requirements for load voltage supply
Example: Littelfuse NLN 30, Bussmann NON-30
Festo — CMMT-ST-C8-1C-...-S0 — 2021-04b
UL 61800-5-1 Adjustable Speed Electrical Power Drive Systems
CSA C22.2 No. 274-17 – Adjustable Speed Drive
4PU8
II
2 (or better)
Class III (SELV/PELV)
for indoor use only
2000 m
UL Listed JDDZ class K5
[A] 30
[kA] 5
[V DC] 125
