Reference Switch [X1C] - Festo CMMT-ST-C8-1C Series Manual

Technical data
10.2.5

Reference switch [X1C]

Digital inputs for the reference switch/limit switch
Specification
Nominal voltage
Permissible voltage
range
Min. input current in
transition range (I
T min
Logic
Delay time in the hard-
ware during switch-on
Delay time in the hard-
ware during switch-off
Max. input voltage
(U ), high level
H max
Min. input voltage
(U ) high level
H min
Max. input voltage
(U ), low level
L max
Min. input voltage
(U ), low level
L min
Max. input current
(I ), high level
H max
Min. input current
(I ), high level
H min
Max. input current
(I ), low level
L max
Tab. 77: Digital Input for Reference Switch/Limit Switch
Voltage for supply of external components at [X1C.1]
Output voltage
Use
Max. output current
Protective function
Tab. 78: Voltage for Supply of External Components at [X1C]
54
Based on type 3 to EN 61131-2; deviating current consumption
[V DC] 24
[V DC] −3 ... 30
[mA] 1.5
)
PNP
< 30
[µs]
< 4000
[µs]
[V] 30
[V] Typically 11
Max. 13
[V] 5
[V] –3
[mA] 15
[mA] 5
[mA] 15
[V DC] +24 (internal logic voltage)
Supply of axis peripheral modules, e. g. reference or limit switch
[mA] 100
– Short circuit to 0 V
– Feedback-proof
NPN
< 4000
< 30
5
Typically 0
30
11
–4
–10
3.43
