Installation
Requirements for the connecting cable
Characteristics
Max. cable length
Tab. 25: Requirements for the connecting cable
The following connections are possible via the Ethernet interface:
Connections
Point-to-point connection
Network connection
Tab. 26: Options for connection
The device supports the following methods of IP configuration (based on IPv4):
Methods
Obtain IP address automatically (DHCP client)
Fixed IP configuration
Tab. 27: Options for IP configuration
Shield support requirements
• Connect the cable shield to the plug housings on both sides.
Possible connections
• Connect CMMT to your network via a hub/switch or directly to the PC.
7.4.5

[XF1 IN] and [XF2 OUT], real-time Ethernet (RTE) port 1 and 2

The real-time Ethernet interface [XF1 IN] and [XF2 OUT] is located on the top of the device. The inter-
face permits RTE communication. The following protocols are supported, depending on the product
version:
Product variant
CMMT-ST-...-EC
CMMT-ST-...-EP
CMMT-ST-...-PN
Tab. 28: Supported protocol
Festo — CMMT-ST-C8-1C-...-S0 — 2021-04b
CAT 5, patch cable, double shielded
30 m
Description
The device is connected directly to the PC via an
Ethernet cable.
The device is connected to an Ethernet network.
Description
The device obtains its IP configuration from a
DHCP server in the network. This method is suit-
able for networks in which a DHCP server already
exists.
The device uses a fixed IP configuration.
The IP configuration of the device can be perma-
nently assigned manually. However, the device
can only be addressed if the assigned IP configu-
ration matches the IP configuration of the PC.
Factory setting: 192.168.0.1
Supported protocol
EtherCAT
EtherNet/IP
PROFINET
