Festo CMMT-ST-C8-1C Series Manual page 50

Technical data
Digital incremental encoder at [X2]
Angle resolution/inter-
polation
Tracking signals A/B/N
Input impedance
A/B/N
Output supply
Support: mechanical
multiturn encoder
Support: battery-buf-
fered multiturn
encoder
Support: encoder
parameter memory
Encoder signal moni-
toring
Protective function
Tab. 70: Digital incremental encoder at [X2]
Absolut encoder with BiSS C protocol
Supply
Resolution
Support: mechanical
multiturn encoder
Support: battery-buf-
fered multiturn
encoder
Support: encoder
parameter memory
Encoder signal moni-
toring
Protective function
Tab. 71: Encoder with BiSS-C protocol
50
4-fold evaluation as 4 steps (2 bits) per period
RS422/485
[Ω] 120 (differential input)
[V] 5.25
[A] Max. 0.5, unregulated (no Sense cable)
No
No
No
No, no direct encoder signal monitoring
No overload protection
[V] 5.25
[A] 0.5
can be parameterised - default: 16 bit
No
No
Yes
Yes
No overload protection
Festo — CMMT-ST-C8-1C-...-S0 — 2021-04b
