Product overview
5
Fig. 4: Elements on the back
1 top hole for wall mounting
2 Retaining screw for t-rail clamp
3 T-rail clamp
There is a hole at the back on top and a slot for wall mounting at the bottom. The t-rail clamp is
mounted in the centre of the back.
Festo — CMMT-ST-C8-1C-...-S0 — 2021-04b
1
2
3
4
4 bottom slot for wall mounting
5 Hood (right side of housing)
