Suction MODULE aspiration performance
The aspiration performance of the Suction MODULE
at any particular time depends on the vacuum set.
The measurements relate to an aspirate bottle with
a capacity of 2 liters.
Aspiration
Vacuum set performance
- 0.2 bar 5.3 l/min
- 0.3 bar 6.5 l/min
- 0.4 bar 8.4 l/min
- 0.5 bar 8.3 l/min
- 0.6 bar 9.0 l/min
Tolerance ±10 %. If the bacteria filter is used,
aspiration performance is reduced by approx. 1 to
3 l/min.
Required
O inlet pressure
2
consumption
6.5 l/min 2.7 – 6 bar
7.7 l/min 2.7 – 6 bar
9.3 l/min 2.7 – 6 bar
10.5 l/min 3.5 – 6 bar
14.0 l/min
Technical data EN
p2
4.5 bar
