16.3 Oxygen output, inhalation

16.4 Aspiration performance

62
EN Technical data
Inlet pressure
in operation
Max. O output
2
Tolerance ±10 %
Maximum performance
Maximum performance for the Combi MODULE and
the Suction MODULE depend on the inlet pressure of
the oxygen supply in operation. The measurements
relate to an aspirate bottle with a capacity of 2 liters.
Inlet pressure Max.
p2 vacuum
2.7 bar – 0.40 bar
3.0 bar – 0.44 bar
3.5 bar – 0.53 bar
4.0 bar – 0.58 bar
4.5 bar – 0.60 bar
5.0 bar – 0.60 bar
5.5 bar – 0.60 bar
6.0 bar – 0.60 bar
Tolerance ±10 %. If the bacteria filter is used,
aspiration performance is reduced as a function of
humidity by approx. 1 to 3 l/min.
2.7 bar 3.0 bar 3.5 bar 6.0 bar
11 l/min 12 l/min 15 l/min 15 l/min
Max. aspiration
performance
8.4 l/min
8.6 l/min
8.8 l/min
9.0 l/min
9.0 l/min
9.0 l/min
8.7 l/min
8.5 l/min
O
2
consumption
9.3 l/min
10.1 l/min
11.4 l/min
12.2 l/min
14.0 l/min
15.0 l/min
17.0 l/min
19.0 l/min
