Technical Data and Installation

Technical Features

SMART KNIT
Terminal
Power supply voltage
Maximum absorption
Dimensions
Operating Temperature range
LCD graphic display
Integrated Touch-pad
Protection
IS3
Sensors
Power supply voltage
Absorption
Reaction Delay
Sensitivity
Signaling
Sensor identification
Dimensions
Temperature range
SM-DIN/KNIT Modules
Power supply voltage
Absorption
2 STOP Outputs (Stop1 - Stop2)
3 Inputs (Slow Ext - Fast Ext -
Reset Ext)
Integrated Touch-pad
Signaling
Dimensions
Operating Temperature range
Mounting type
Protection
Power Supply
Power supply voltage (*)
(*) The supply voltage to SMART KNIT terminal is provided by the connection
cable between terminal and SM-DIN interface module.
SMART KNIT
2 2 2 2 – – – – TECHNICAL DATA AND INSTALLATION TECHNICAL DATA AND INSTALLATION
TECHNICAL DATA AND INSTALLATION TECHNICAL DATA AND INSTALLATION
15 Vac or 24 Vdc ± 10%
150 mA
135 x 95 x 40 mm
0° - 60 °C
80 x 40 mm
5 membrane buttons with integrated red LED
2 fuses 5 x 20 – 1A
24 Vdc ± 20%
Typical 17 mA (max 20 mA)
Programmable from 5 to 1000 msec
Programmable (10 levels)
With integrated LEDs (red – green)
Through "Touch Light"
25 x 35 x 10 mm
0° - 60 °C
15 .. 24 Vac or 24 Vdc ± 10%
Typical 0.2 A - Max 2 A
NO/NC relay contacts: 0-24 Vac
NO/NC relay contacts: (0-24 Vdc)
3 push buttons
3 digit display + 8 signaling LEDs
138 x 125 x 35 mm
10° - 70 °C
Inside the cabinet: on DIN rail, or fastening
screws.
On panel: with cover plates
Self-restoring fuse, 5A
15..24 Vac ± 10% (by transformer)
or 24 Vdc ± 10%
- 2.1 -
