SM-DIN Module Configuration

Procedure
3 sec.
- 3.4 -
The SM-DIN sensor interface modules require the programming of 2 parameters
only:
- Identification number of SM-DIN modules within the system (1 to 8)
Communication speed (Baudrate) between SMART KNIT and SM-DIN
-
(115,2 or 57,6 Kbps)
During the normal machine operation
Parameter 01 (SM-DIN module identification number)
To increase the value (max. 8)
To decrease the value (min. 1)
Parameter P02 (Baudrate)
To select 57.6 Kbps or 115.2 Kbps
(Default = 115.2 Kbps) (*)
(*) Always set 115.2 Kbps
