SIEB & MEYER SD2 Series Hardware Description page 168

General Information Regarding the Wiring
▸
The cable shields must be connected to the connector shell inside of the connec-
tors. In the switch cabinet they should be connected to a ground bus.
▸
Cable shields not ending in a connector inside of the switch cabinet such as motor
cables must be connected to the ground bus.
▸
Both ends of the shield of shielded cables must generally be connected to the shell.
The line cross-sections should be selected carefully so that the maximum admissible
current is not exceeded at the maximum ambient temperature (see technical data). DIN
VDE 0298-4 defines the admissible values for the individual line cross-sections, which
must absolutely be taken into account.
The current carrying capacity in connection with the line cross-section of copper con-
ductors isolated with PVC or cables according to DIN VDE 0298-4 for different types of
wiring are indicated in the following table: All values are related to an ambient temper-
ature of +40 °C and an operating temperature at the conductor of 70 °C.
Conductor
cross-sec-
tion A [mm²]
0.75
1.00
1.50
2.50
4
6
10
16
25
35
50
70
95
120
150
185
240
300
400
500
630
Tab. 2: Current carrying capacity according to DIN VDE 0298-4
(1)
B2 wiring: wiring in installation tubes or closed installation channels.
(2)
E wiring: Free wiring of one cable with a min. distance of 0.3 × cable diameter to the wall.
(3)
F wiring: Free wiring of several cables with a min. distance of 1 × cable diameter to the wall.
For detailed information refer to the standard IEC 60364-5-52 and the documents of the
cable manufacturer.
168
Admissible current I [A]
E wiring (3 ca-
(1)
B2 wiring
ble leads)
7.6
9.6
12.2
16.5
23
29
40
53
67
83
100
130
150
175
–
–
–
–
–
–
–
Drive System SD2 - Hardware Description
F wiring (3 ca-
(2)
ble leads)
10.4 –
12.4 –
16 –
22 –
30 –
37 –
52 –
70 –
88 96
110 119
133 145
171 188
207 230
240 268
277 309
317 356
374 422
433 488
– 570
– 652
– 744
(3)
