Safety Instructions
▸
Protect the device against mechanical damage! Ensure that single shock loads do
not exceed 40 m/s
▸
Protect the device against dirt and humidity.
Make sure that dust plugs are plugged on optical fiber connectors equipped
with them during transport of the device. Otherwise, recommissioning is poten-
tially not possible.
▸
Never touch electronic components.
The following climatic conditions apply to the storage. If required, appropriate measures
must be taken to ensure these climatic conditions (installation of heating/air conditioning
systems etc.):
▸
The storage area must be clean (dust-free, if possible), dry and well-ventilated.
▸
No storage in the open.
▸
The storage temperature must be in the range of −25 °C to +55 °C (−13 °F to
+131 °F). Shortly it may be +70 °C (+158 °F).
▸
The relative humidity on the storage premises must be in the range of 5 % to 75 %
(no bedewing).
▸
Sudden changes of the temperature or the humidity should be prevented.
▸
Avoid stacking of the devices during transport and storage.
The maximum storage period is 2 years. Electrolytic capacitors produce high leakage
currents when a voltage is applied after a long storage period without applied voltage
and must be reformed. For this, the operating voltage is applied via a 1 kΩ series resistor
for one hour. Please contact the SIEB & MEYER service department for details.
3.6

Installation

Damage of electrostatically sensitive components due to improper handling
→ Never touch electronic components..
Note
Consider specific mounting instructions for your device.
Mechanical installation conditions for the system according to DIN EN 61800-2:
„Vibrations must remain within the limit values of the IEC 60721-3-3,
class 3M1,standard for fixed equipment."
Frequency [Hz]
Tab. 1: Vibration limits of the system
"Vibrations which exceed these limits, or the use on mobile equipment, are considered
as abnormal mechanical conditions."
Operating conditions:
The following requirements are to be considered for the installation and the operation of
the device. Noncompliance with theses requirements is regarded as abnormal operat-
ing condition:
14
2
.
2 ≤ f < 9
9 ≤ f < 200
NOTICE
Amplitude [mm]
0.3
Not applicable
Drive System SD2 - Hardware Description
Acceleration [m/s²]
Not applicable
