If the backup battery is depleted, there is no effect
on the operation of the flame detector, but the time
stamping of the data log may be affected.

FEATURES

• Responds to a fire in the presence of modulated
blackbody radiation (i.e., heaters, ovens, turbines)
without false alarm
• High speed capability
• Built-in data logging / event monitoring, up to 1500
events (up to 1000 general, 500 alarms)
• Pulse output for compatibility with controller based
systems
• Microprocessor controlled
increased resistance to moisture and ice
• Automatic, manual or magnetic o i testing
• Easily replaceable o i plate
• Fire and fault relays
• A tri-color LED on the detector faceplate indicates
normal condition and notifies personnel of fire alarm
or fault conditions
• Operates under adverse weather conditions
• Mounting arm allows easy sighting
• Integral wiring compartment for ease of installation
• Explosion-proof/flame-proof
Meets FM, CSA, ATEX, and IECEx certification
requirements
• Class A wiring per NFPA-72 (relay connections).
(Pulse output is equivalent to class A when detectors
are installed in a redundant configuration.)
• 3 year warranty
• Advanced signal processing (ARC/TDSA)
• RFI and EMC Directive Compliant
9.2
NOTE
heated optics
detector housing.

SPECIFICATIONS

OPERATING VOLTAGE—
24 Vdc nominal (18 Vdc minimum, 30 Vdc maximum).
Maximum ripple is 2 volts peak-to-peak.
For CSA compliance, the power source must use
a SELV (Safety Extra Low Voltage) or Class 2 style
power supply.
POWER CONSUMPTION—
Without heater: 2.8 watts at 24 Vdc nominal;
3.1 watts at 30 Vdc nominal;
Heater only: 8 watts maximum.
Total power: 17.5 watts at 30 Vdc with EOL resistor
installed and heater on maximum.
EOL resistor must be ceramic, wirewound type, rated
for
5 watts minimum, with actual power dissipation not to
exceed 2.5 watts.
POWER UP TIME—
Fault indication clears after 0.5 second; device is ready
to indicate an alarm condition after 30 seconds.
OUTPUT RELAYS—
Fire Alarm relay, Form C, 5 amperes at 30 Vdc:
The Fire Alarm relay has redundant terminals and
normally open / normally closed contacts, normally
de-energized operation, and latching or non-
latching operation.
Fault relay, Form A, 5 amperes at 30 Vdc:
The Fault relay has redundant terminals and
normally open contacts, normally energized
operation, and latching or non-latching operation.
TEMPERATURE RANGE—
Operating: –40°F to +167°F (–40°C to +75°C).
Storage: –67°F to +185°F (–55°C to +85°C).
Hazardous location ratings from –55°C to +75°C available
on flameproof model.
HUMIDITY RANGE—
0 to 95% relative humidity, can withstand 100%
condensing humidity for short periods of time.
19
4.8 watts at 24 Vdc in alarm.
5.4 watts at 30 Vdc in alarm.
