CITO RSP System 2.0 Operating Manual page 81

Example:
Cylinder undercuts
blanket cylinder
2.30 mm
2.60 mm
2.80 mm
3.00 mm
3.20 mm
Maschine:
Importand note:
In some cases there is already foil glued to blanket cylinders the thickness of which must
be taken into account when determining the packing thickness!
Exception: No extra packings necessary with the XL 105 Coating Unit.
Total thickness base Total thickness base
plate with mounted plate with RSP direct
RSP form fit flexible dies
2.30 mm
2.30 mm
2.30 mm
2.30 mm
2.30 mm
Total thickness
calibrated packing
sheets
2.00 mm no packing sheets
2.00 mm 0.30 and 0.20 mm
(manroland)
2.00 mm 0.50 mm
2.00 mm 0.70 mm
2.00 mm 0.90 mm
