Light Indicators

© Danfoss | DCS (ms) | 2021.03
21HL1 21HL2
PURGING
Progeco srl LARGEST MOTOR
4,19A
FLA
LARGEST RESISTANCE
MODEL DANFOSS INTELLIGENT
0,24A
PURGING SYSTEM (IPS 8) – NAM RLA
SCCR CURRENT
WIRING DIAGRAM RIV19E01 18kA
ELECTRIC SUPPLY 1PH + N/GRD CONSTRUCTION YEAR 03 / 2020
230V 60Hz
ENCLOSURE
TYPE 12
FULL LOAD CURRENT 6,2A RATING
Via Laghi, Calcinelli (PU)
Industrial control panel for general use www.progecoautomazione.it
Fig. 25
Lights ON Status
Green Stand by
Yellow Run
Green & Yellow Purging
Green & Yellow Uninterupted Long time
& Red purging (> 150 h)
Occurs when: Check list
Red
of alarms description
* The purger continuous purging until max running period (default 160 h) is reached and the purger compressor will stop
** The purger compressor stops when alarm occurs
21HL3
21HL1
Compressor Compressor
ON OFF
x
x
x
x
(x**) x**
21HL2
PURGING
Purge Valve Purge Valve
ON OFF
x
x
x
x*
BC344024774466en-000201 | 19
21HL3
Alarm
x
