Touch Control Connector (TCTRL1)

Pin Signal Pin
1 +5V 21
2 NC 22
3 +12V 23
4 NC 24
5 NC 25
6 -12V 26
7 NC 27
8 NC 28
9 +5V 29
10 NC 30
11 NC 31
12 KB_P14 32
13 AUX_CLK 33
14 AUX_DATA 34
15 H8_CLK 35
16 H8_DATA 36
17 NC 37
18 GND 38
19 TCH_LED* 39
20 NC 40
Signal
GND
KB_AIN0
GND
KB_AIN1
GND
RESET
NC
TXD2
NC
TCH_RXD2
NC
+5V
NC
AUX_DATA
AUX_CLK
UL
LL
SENSE
LR
UR
