Power Connectors (DCPWR1)

DCPWR1 is a six-pin connector.

Touch Control Connector (TCTRL1)

TCTRL1 is a 40-pin latching connector providing touch screen control.
Pin Signal
1 +12V
2 +5V
3 +5V
4 GND
5 GND
6 -12V
Pin Signal Pin
1 +5V 21
2 NC 22
3 +12V 23
4 NC 24
5 NC 25
6 -12V 26
7 NC 27
8 NC 28
9 +5V 29
10 NC 30
11 NC 31
12 NC 32
13 NC 33
14 NC 34
15 NC 35
16 NC 36
17 NC 37
18 GND 38
19 TCH_LED* 39
20 NC 40
Signal
GND
NC
GND
NC
GND
RESET
NC
TXD2
NC
TCH_RXD2
NC
+5V
NC
AUX_DATA
AUX_CLK
UL
LL
SENSE
LR
UR
27
