Hardware Specifications

Characteristic
Power Specifications:
power supply on the AHIP-370
provides a voltage range of 1.30V
to 2.05V in increments of 50mV.
The CPU selects its voltage
through its four outputs VID3-
VID0. The supply was changed to
accommodate future Socket370
CPUs which will run at lower volt-
ages.
CPU speed
AGP Super VGA Graphics Con-
troller
Serial Ports (2)
Parallel Interface
On-board memory
Table 1-2. Hardware Specifications
The maximum current that the supply can deliver is 19A.
The CPU
300 MHz, 366 MHz, and 433 MHZ
640x480, 800x600, and 1024x768, 64K colors maximum resolution
2 MB video DRAM
COM1 is RS-232 or RS-485
COM2 is RS-232, or IR, or Touchscreen
Both 16550 compatible
Centronics compatible
Up to 256 MB; 66 MHz SDRAM
Chapter One - Introduction
Specification
