DCIN1 Power Connector (PWR1)

-5V is not provided by the power supplies and will have to be created on
the backplane board.
52
Pin Signal
1 3.3V
2 3.3V
3 GND
4 +5
5 GND
6 +5
7 GND
8 NC
9 5VSB
10 +12
11 3.3V
12 -12
13 GND
14 PSON
15 GND
16 GND
17 GND
18 -5
19 +5
20 +5
Note
