Appendix C– Pinouts
This appendix describes the pinouts for the AHIP-370 connectors defined in Chapter
2.
VGA Connector (VGA1)
Pin
Signal
1
RED
2
GREEN
3
BLUE
4
NC
5
ORB_GND
6
ORB_GND
7
ORB_GND
8
ORB_GND
9
Fused VCC
10
ORB_GND
11
NC
12
DDCDAT
13
HSYNC
14
VSYNC
15
DDCCLK
NC = no connect
Appendix C - Pinouts
49
