Internal Keyboard Connector (KYBD1)

PS/2 Keyboard/Mouse Connector (KBMS1)

If the touchscreen controller is using the mouse port, this interface will
not be available.

Internal Floppy Connector (FDD1)

Pin Signal
1 KB_CLK
2 GND
3 KB_DATA
4 5VFUSE
5 SPEAKER
Note
Pin Signal Pin
1A KB_DATA 1B
2A NC 2B
3A GND 3B
4A 5VFUSE 4B
5A KB_CLK 5B
6A NC 6B
Pin Signal Pin
1 +5V 14
2 IDX* 15
3 +5V 16
4 FDS1* 17
5 +5V 18
6 DCHG* 19
7 NC 20
8 NC 21
9 NC 22
10 MO1* 23
11 NC 24
12 FDIRC* 25
13 NC 26
Signal
AUX_DATA
NC
GND
5VFUSE
AUX_CLK
NC
Signal
FSTEP*
GND
FWD*
GND
FWE*
GND
FTK0*
GND
FWP*
GND
FRDD*
GND
FHS*
Appendix C – Pinouts
