Xycom AHIP-370 Manual page 61

Pin Signal
45 HDDRQ0
46 GND
47 HDD(7)
48 HDD(6)
49 HDD(5)
50 HDD(4)
51 HDD(3)
52 HDD(2)
53 HDD(1)
54 HDD(0)
55 HDIOW*
56 HDIORDY
57 IDE_IRQ
58 HDA0
59 HDCS0*
60 IDEACTP*
Pin Signal
105 DRQ7
106 MASTER16*
107 IDERST*
108 HDD(8)
109 HDD(9)
110 HDD(10)
111 HDD(11)
112 HDD(12)
113 HDD(13)
114 HDD(14)
115 HDD(15)
116 HDIOR*
117 HDIOCS16*
118 HDA1
119 HDA2
120 HDCS1*
Appendix C – Pinouts
61
